8471 - 300V LSZH Alternative Cable
8471 Alternative cable is suitable for use in instrumentation, security, data and audio applications where protection against electrical interference is not required.
APPLICATION 8471 Alternative cable is suitable for use in instrumentation, security, data and audio applications where protection against electrical interference is not required. For installations where fire, smoke emission and toxic fumes create a potential risk to life and equipment. |
CHARACTERISTICS Voltage Rating 300V Temperature Rating Fixed: -20ºC to +80ºC |
CONSTRUCTION
Conductor
Class 2 stranded tinned copper
Insulation
HDPE (High Density Polyethylene)
Sheath
LSZH (Low Smoke Zero Halogen)
Core Identification
Pair 1: Black White
Sheath Colour
● Grey
