8761 600V LSZH Alternative Cable
A single pair overall screened LSZH (Low Smoke Zero Halogen) cable, suitable for use in instrumentation, data and audio applications where protection from electrical interference is required.
APPLICATION A single pair overall screened LSZH (Low Smoke Zero Halogen) cable, suitable for use in instrumentation, data and audio applications where protection from electrical interference is required. For installations where fire, smoke emissions and toxic fumes create a potential risk to life and equipment. |
CHARACTERISTICS Voltage Rating 600V Temperature Rating -25ºC to +90ºC |
CONSTRUCTION
Conductor
Class 2 stranded tinned copper conductor
Insulation
HDPE (High Density Polyethylene)
Shield
Al/PET (Aluminium/Polyester Tape)
Drain Wire
Tinned copper
Sheath
LSZH (Low Smoke Zero Halogen)
Core Identification
● Black oWhite
Sheath Colour
● Violet
