Aluminium Split Concentric BS 7870 LSZH Cable
Used by distribution network operators (DNO’s) when providing the final connection to domestic properties.
$15.00
APPLICATION
Used by distribution network operators (DNO’s) when providing the final connection to domestic properties. Also suitable for sub main distribution and particularly used within high-rise buildings and street lighting systems.
APPLICATION Used by distribution network operators (DNO’s) when providing the final connection to domestic properties. Also suitable for sub main distribution and particularly used within high-rise buildings and street lighting systems. |
CHARACTERISTICS Voltage Rating (Uo/U) 0.6/1kV Temperature Rating -15°C to +70°C Minimum Bending Radius 8 x overall diameter |
CONSTRUCTION
Conductor
Class 1 solid aluminium conductor
Insulation
XLPE (Cross-Linked Polyethylene)
Neutral Conductor
Plain copper wires covered a blue polymeric compound
Earth Continuity Conductor
Plain copper wires
String Separator
Non-hygroscopic separator
Sheath
LSZH (Low Smoke Zero Halogen)
Sheath Colour
Orange
STANDARDS
BS 7870-3-21, EN 60228
