AXQJ 1kV Cable
The AXQJ 1kV cable is suitable for use in fixed installation, both indoors and outdoors in air, ground and water.
APPLICATION The AXQJ 1kV cable is suitable for use in fixed installation, both indoors and outdoors in air, ground and water. |
CHARACTERISTICS Voltage Rating Uo/U 0.6/1kV Temperature Rating Minmum installation: -10°C Operating: -30°C to +90°C Maximum Short-Circuit: 250°C Minimum Bending Radius Fixed: 8 x overall diameter Flexed: 12 x overall diameter |
CONSTRUCTION
Conductor
Sector Shaped Stranded Aluminium
Insulation
XLPE (Cross-Linked Polyethylene)
Inner Sheath
HFFR (Halogen free flame retardant)
Screen
Annealed copper wires with opposite open helix of copper
Outer Sheath
HFFR (Halogen free flame retardant)
Core Identification
3 core: ● Brown ● Black ● Grey
4 core: ● Blue ● Brown ● Black ●Grey
Sheath Colour
● Black
