Cat 5E 25 Pair U/UTP LSZH Cable
High performance 25 pair LSZH backbone cable suitable for 100Base-T, Gigabit Ethernet, 155 Mbps ATM, TP-PMD audio, multimedia and telephone networks.
CHARACTERISTICS
Temperature Rating
Fixed: -20°C to +60°C
Minimum Bending Radius
Full load: 20 x overall diameter
No load: 15 x overall diameter
CONSTRUCTION
Conductor
Class 1 solid copper conductor
Insulation
HDPE (High Density Polyethylene)
Filler
PE (Polyethylene) filler core
Separator
Mylar tape
Sheath
LSZH (Low Smoke Zero Halogen)
Sheath Colour
Grey
