H05V3V3H6-F/ H05V3V3D3H6-F
Cable
Application and Description
This kind of flat cables are used in crews of elevators for people and have burdens, and conducting very swift and hard parts of machines.
H05V3V3H6-F type cables having no strechter carrier elements are adviced to use in elevator instalations max. swift not pass 4.0 m/s.These cables freely hanging height is max. 45m and movement limit is max 80m.
For the H05V3V3D3H6-F, at the swifts between 4.0/s to 6.3m/s, it’s adviced to use the cables having strechter carrier elements. H05V3V3D3H6-F type cables freely hanging height is max. 80m movement limit is max. 150m.
Standard and Approval
NF C 32-070
CSA C22.2 N° 49
Cable Construction
Bare copper strand conductor |
acc. to DIN VDE 0295 class 5/6 resp. IEC 60228 class 5/6 |
PVC T15 core insulation |
Color coded to VDE 0293-308, >6 wires black with white numerals with green/yellow wire |
Black PVC TM 4 sheath |
Technical Characteristics
Working voltage | 300/500V |
Test voltage | 2000V |
Flexing temperature | - 35°C - +70°C |
Flame retardant | NF C 32-070 |
Insulation resistance | 350 MΩ x km |
