LiHCH Screened LSZH Cable
APPLICATION For signal transmission between electronic devices, in computer systems or process control units with requirements to electromagnetic compatibility.
APPLICATION For signal transmission between electronic devices, in computer systems or process control units with requirements to electromagnetic compatibility. |
CHARACTERISTICS Voltage Rating 250V Temperature Rating Fixed: -30ºC to +70ºC Minimum Bending Radius Fixed: 7.5 x overall diameter Fixed: 15 x overall diameter |
CONSTRUCTION
Conductor
Generally to Class 5 flexible stranded copper
Insulation
LSZH (Low Smoke Zero Halogen)
Screen
TCWB (Tinned Copper Wire Braid)
Outer Sheath
LSZH (Low Smoke Zero Halogen)
Core Identification Core 1: o White Core 2: Brown Core 3: Green Core 4: Yellow Core 5: Grey Core 6: Pink Core 7: Blue Core 8: Red Core 9: Black Core 10: Violet Core 11: Grey/Pink Core 12: Red/Blue Core 13: White/Green | Core 14: Brown/Green Core 15: White/Yellow Core 16: Yellow/Brown Core 17: White/Grey Core 18: Grey/Brown Core 19: White/Pink Core 20: Pink/Brown Core 21: White/Blue Core 22: Brown/Blue Core 23: White/Red Core 24: Brown/Red Core 25: White/Black Sheath Colour Grey |
