PAS BS 5308 Part 1 Type 1 SIL/CAM/LSZH (Fire Resistant) Cable
Publicly Available Standard (PAS) BS 5308 cables are designed to carry communication and control signals in a variety of installation types including those found in the petrochemical industry.
APPLICATION
Publicly Available Standard (PAS) BS 5308 cables are designed to carry communication and control signals in a variety of installation types including those found in the petrochemical industry. The signals can be analogue, data or voice type and from a variety of transducers such as pressure, proximity and microphone. Part 1 Type 1 cables are generally designed for indoor use and in environments where mechanical protection is not required. Suitable for fire resistant installations.
CHARACTERISTICS
Voltage Rating Uo/U 300/500V
Operating Temperature
Fixed: -40ºC to +80ºC
Flexed: 0ºC to +50ºC
Minimum Bending Radius
Fixed: 6 x overall diameter
CONSTRUCTION
Conductor
0.5mm² - 0.75mm²: Class 5 flexible copper conductor 1mm² and above: Class 2 stranded copper conductor
Insulation
Silicone rubber ceramic type
Screen
Al/PET (Aluminium/Polyester Tape)
Drain Wire
Tinned copper
Sheath
LSZH (Low Smoke Zero Halogen)
Sheath Colour
● Red Black
