Profinet Type A Cable
Profinet cable Type A with solid copper conductors for the cabling of industrial field bus systems with the globally accepted TCP/IP protocol.
$15.00
APPLICATION
Profinet cable Type A with solid copper conductors for the cabling of industrial field bus systems with the globally accepted TCP/IP protocol. Suitable for fixed or flexible applications. Cable properties include a high active and passive interference resistance. They are free from paint wetting disruptive substances (LABS-free).
CHARACTERISTICS
Voltage Rating
300V
Temperature Rating
Fixed: -20°C to +70°C
Minimum Bending Radius
Fixed: 7.5 x overall diameter
Flexed: 15 x overall diameter
CONSTRUCTION
Conductor
Class 1 solid copper conductor
Insulation
LSZH (Low Smoke Zero Halogen)
Bedding
LSZH (Low Smoke Zero Halogen)
Screen 1
Al/PET (Aluminium Polyester Tape)
Screen 2
TCWB (Tinned Copper Wire Braid)
Sheath
LSZH (Low smoke Zero Halogen)
Core Identification
O White ● Blue Orange
Sheath Colour
● Green
