PUR Industrial Ethernet Cable
STANDARDS IEC 61156-6, BS EN 60811-404
APPLICATION
Industrial Ethernet cable suitable for Profinet Type B applications. Can be used in dry or damp rooms for plant engineering and machinery manufacturing. The rugged polyurethane sheath provides protection even in extreme industrial environments.
CHARACTERISTICS
Temperature Rating
Fixed: -40ºC to +80ºC
Flexed: -20ºC to +70ºC
Minimum Bending Radius
Fixed: 8 x overall diameter
Flexed: 12 x overall diameter
CONSTRUCTION
Conductor
Stranded bare copper wires (AWG24/7)
Insulation
FPE (Foam Skin Polyethylene)
Separator Tape
PET (Polyester)
Pair Shield
Al/PET (Aluminium Polyester Tape)
Braid
TCWB (Tinned Copper Wire Braid) 90% coverage
Sheath
PUR (Polyurethane)
Pairs Identification
Pair 1: White Green
Pair 2: White Orange
Pair 3: White Blue
Pair 4: White Brown
Sheath Colour
● Green
