RF12(1/2″)
Cable
Construction
Inner conductor | Copper clad Aluminium | Φ4.83 mm |
Dielectric | Foam PE | Φ12.95 mm |
Outer conductor | Corrugated copper | Φ13.97 mm |
Sheath | LSZH SHF2 | Φ15.88 mm |
Fire Performance
Flame Retardant (Single Vertical Wire Test) | IEC60332-1 |
Reduced Fire Propagation | IEC60332-3-22 (CATA) |
Electrical & Mechanical Characteristics
Impedance | 50±3 Ohm |
Nominal capacitance | 76 pF/m |
Velocity of propagation | 88% |
Insulation resistance | >5000 Mohm.Km |
Inner conductor resistance | ≤1.62 Ohm/Km |
Outer conductor resistance | ≤4.30 Ohm/Km |
Installation temperature range | -25°C - +60 °C |
Operating temperature range | -40°C - +85°C |
Test voltage | 4 KV |
Cable weight (approx.) | 220 kg/km |
Maximum Operating Frequency | 8.8 GHz |
Screening effectiveness | >120dB |
